Overview

Dimensions

Ø118 x 111 mm (Ø4.6 x 4.4")

IR Night Vision

40 m (131 ft)

Face Recognition

Yes

License Plate Recognition

Yes

Smart Detections (People, Vehicles, Animals)

Yes

Resolution

4K

Field of View

H: 109.9°, V: 56.7°, D: 134.1°

Audio

Two-way audio

Weatherproofing

IP66

Tamper Resistance

IK08

Mounting

Ceiling, arm, wall, pendant mount, junction box

Performance

Networking Interface

GbE RJ45 port

Video

Image Settings

Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay, HDR

Max. Frame Rate

30 FPS

Resolution

8MP 3840 x 2160 (16:9)

Optics

Sensor

1/1.8" 8MP

Lens

Fixed focal length

Night Mode

Built-in IR LED illumination and IR cut filter

Hardware

Max. Power Consumption

20W

Supported Voltage Range

42.5—57V DC

Power Method

PoE+

Processor

Quad-core Arm® Cortex®-A53 based chip

Weight

990 g (2.2 lb)

Enclosure Material

Aluminum alloy, polycarbonate

Button

(1) Factory-reset

Ambient Operating Temperature

-30 to 50º C (-22 to 122º F)

Ambient Operating Humidity

0 to 90% noncondensing

Certifications

CE, FCC, IC

NDAA Compliant

Yes

Cable

Cable Connector Type

RJ45

Cable Diameter

4.5 mm (0.2")

Cable Length

30 cm (1 ft)

Jacket Material

Thermoplastic elastomer

Jacket Enclosure Dimensions

Ø20 x 70.6 mm (0.8 x 2.8")

Jacket Enclosure Material

Thermoplastic elastomer, polycarbonate, silicone rubber

Expansion Slot

MicroSD Card
